Folding wall-mount racks
The number that matters is how far the rack sticks out once folded. Three makers, four depths, all on one table.
REP, Rogue and Titan product pages, read Oct 2, 2026.
| If you are asking | Start with | Link |
|---|---|---|
| Need the car back in every night? | A shallow rack: 5 to 6 in folded | Compare |
| Want room to step back inside? | A deep version, 41 to 41.5 in | Compare |
| Lowest listed price? | Titan T-3 folding, $399.97 | See Titan |
| Low garage ceiling? | Titan T-3 folding, 82.375 in | See Titan |
How it folds. REP's 21.5 in rack folds in on itself to 6 in; its 41 in rack folds left and right and takes 24 in1. Rogue says that with the 41.5 in depth both sides fold outward, or one in and one out, and that it stows to less than 5 in2. Titan lists 5 in folded3.
Width on the wall. REP lists 48 in overall width1, Titan 46 in3, and Rogue 49 in outside the uprights (56.1875 in overall on the wall)2. Measure between studs, doors and windows.
Mounting. These racks attach to the wall and are only as solid as that attachment. Follow the maker's mounting instructions; REP says its 1,000 lb rackable capacity applies when properly mounted1.
| Rack | Height | Depth when open | Folded, from the wall | Listed price |
|---|---|---|---|---|
| Titan T-3 Series folding (82 in)3 | 82.375 in | 22.5 in from the wall | 5 in | $399.97 |
| REP PR-4100 (21.5 in deep)1 | 92.3 in uprights | 21.5 in | 6 in | $499.99 |
| REP PR-4100 (41 in deep)1 | 92.3 in uprights | 41 in | 24 in | $579.99 |
| Rogue RML-3W2 | 90.375 in uprights | 21.5 or 41.5 in inside | Less than 5 in | $605.00 |
| Source | Product pagesRead Oct 2, 2026 | Product pagesRead Oct 2, 2026 | Product pagesRead Oct 2, 2026 | Product pagesRead Oct 2, 2026 |
From each merchant's page, October 2, 2026. Rogue's page shows $605.00 for the rack with the default options; check the price for the depth you choose. Titan also sells a 91 in height and a 41.5 in depth version of its folding rack.
How these links work: each button opens the merchant's own product page. We are not paid for these links today; we may earn a commission from purchases in the future.
Good for lower garage ceilings, folds to 5 in
Good for 3 x 3 in uprights that stow under 5 in
Good for a choice of 21.5 or 41 in depth
Measure from the wall to the bumper with the car in its usual spot.
46 to 49 in of wall, clear of doors, windows and outlets123.
Follow the maker's instructions; capacity depends on it1.
82.375 in for the Titan, 90 to 92 in uprights on the others123.
The shallow version (about 21.5 in) folds closest to the wall12. The deep version gives more room to step back inside the rack but folds out further on REP's design (24 in)1.
Titan lists an 80 in max pull-up height on its 82 in folding rack3. Check the pull-up bar position on the others' pages.
We do not earn anything from purchases today. Every product link is a plain link to the merchant's own page, without an affiliate code. We may join merchants' affiliate programs in the future, and this notice will say so before that changes.
Prices, dimensions and shipping belong to each merchant and can change. The merchant's own page is the final word on price, availability and terms.
GymFloor Planner compares published dimensions. We have not installed or lifted on this equipment; measure your own room and follow the maker's installation instructions.
